Description
REV170103P
| Part number | 8941077210 | |
| Model | CP7721 | |
| Handle type | Butterfly | |
| Square drive | 3/8″ | |
| Working Torque Range (fwd) | 9-80 Nm | 6.6-59 |
| Maximum Torque (reverse) | 110 Nm | 81 ft.lbs |
| Free speed | 15000 rpm | |
| Blows per minute | 10500 | |
| Net weight | 0.53 kg | 1.1 lb |
| Power/weight ratio | 220 Nm/kg | 73.6 ft.lb/lb |
| Length | 140 mm | 5 1/2″ |
| Side to center | 40 mm | 1.6″ |
| Average air consumption | 0.7 l/s | 1 1/2 cfm |
| Actual air consumption | 2.9 l/s | 6 cfm |
| Air inlet thread size | 0.25 ” | |
| Min. hose size | 10 mm | 3/8″ |
| Noise level | 92 db(A) | |
| Sound Power | 103 db(A) | |
| Vibration α (ISO-28927-2) | 4 m/s² | |
| Vibration K (ISO-28927-2) | 1 m/s² | |
| Socket retainer | Friction ring | |
| Clutch type | Rocking dog clutch |
